Liftgate

WALTCO/ZEPRO MAGNETIC COIL 12V
• 2-Wire, 13mm Bore

WALTCO MOMENTARY TILT SWITCH 2-WIRE

WALTCO SPRING REPLACEMENT KIT

BUCHER HYDRAULIC POWER PACK 12V 2500PSI
• Power-Up/Gravity-Down
• 1 Gallon Poly Reservoir

BUCHER HYDRAULIC POWER PACK 12V 2500PSI
• Power-Up/Gravity-Down
• 2 Gallon Poly Reservoir

MAXON POLY RESERVOIR
• Overall Tank Length with Collar 8.00"
• Tank Length 5.00"
• Tank Width 6.50"
• Tank Height 6.00"
• Collar Length 3.00"
• 3 Quarts Useable

WALTCO UPPER LIFT CYLINDER PIN
• 7-7/8" Long x 1" Diameter
• 1/4" Cap Screw Holes(2)

WALTCO LIFTGATE PIN
• 94mm Long x 32mm Diam.

WALTCO CYLINDER COVER

WALTCO PLATFORM TORSION SPRING

WALTCO FOLDING PLATFORM HINGE PIN

WALTCO EXTERIOR MOUNT MOLDED TOGGLE SWITCH
• Up/Down - Open/Close
• 120" Harness W/Round 6-Pin Deutch Connector

ACTIVATION COIL 12V INSULATED
• 2 Wire Deutsch Connector

THIEMAN SEALED CONTROL SWITCH
• 4-Wire with 9" Rear Leads

MAXON CONTROL SWITCH POWER-DOWN/POWER-UP

KTI HYDRAULIC POWER PACK 12V 2500PSI
• Power-Up/Power-Down
• 0.75 Gallon Poly Reservoir

WALTCO HYDRAULIC POWER PACK 12V 3000PSI
• Power Up / Power Down

MAXON LOW VOLTAGE THERMAL SWITCH
• Red LED-Motor Temp, Green LED-Voltage

BUCHER HYDRAULIC POWER PACK 12V 2500PSI
• Power-Up/Power-Down
• 1 Gallon Poly Reservoir

MAXON REMOTE LIFTGATE CONTROL SWITCH
• 3-Button Monentary Up-Tilt-Down

MAXON PLATFORM TORSION BAR

WALTCO/ZEPRO LIFT & TILT CYLINDER PROTECTIVE COVER
• DIM: 352mm L x 40/85mm ID

WALTCO HYDRAULIC FLOW CONTROL VALVE
• 3/8-NPT X 3/8-NPT

MAXON FLEXIBLE CABLE ASSEMBLY

MAXON PASSENGER SIDE TORSION SPRING
• 8-1/2" Long x 5/8" Diameter

THIEMAN HYDRAULIC POWER PACK

LEYMAN RIGHT HAND PIVOT SPRING
