Reservoirs

WALTCO POLY RESERVOIR
• Overall Length with Collar 13.00"
• Tank Width 6.50"
• Tank Height 6.00"
• Collar Length 3.00"
• 1.50 Gallons Useable

WALTCO POLY RESERVOIR
• Tank Length 13.00"
• Tank Diameter 4.50"
• Single Hole
• 1.75 Quarts Useable

WALTCO STEEL RESERVOIR
• Tank Length 13.00"
• Tank Diameter 4.50"
• Single Hole
• Horizontal Mount
• 1.75 Quarts Useable

BUCHER POLY RESERVOIR
• Overall Length with Collar 15.00"
• Tank Length 13.00"
• Tank Width 6.75"
• Tank Height 6.75"
• Collar Length 2.00"
• 1.67 Gallons Useable

MAXON HORIZONTAL MOUNT POLY RESERVOIR 1 GALLON
• Cap not Included

MAXON POLY RESERVOIR
• Overall Tank Length with Collar11.00"
• Tank Length 8.00"
• Tank Width 6.50"
• Tank Height 6.00"
• Collar Length 3.00"
• 1.25 Gallons Useable

DALTON POLY RESERVOIR
• Overall Length with Collar 20.00"
• Tank Width 6.50"
• Tank Height 6.00"
• Collar Length 3.00"
• 2.50 Gallons Useable

BUCHER POLY RESERVOIR
• Overall Length with Collar 12.40"
• Tank Length 10.90"
• Tank Width 3.25"
• Tank Height 5.38"
• Collar Length 1.50"
• 1.89 Quarts Useable

BUCHER POLY RESERVOIR
• Overall Length with Collar 20.32"
• Tank Length 19.00"
• Tank Width 3.25"
• Tank Height 5.38"
• Collar Length 1.00"
• 2.16 Quarts Useable

BUCHER POLY RESERVOIR
• Overall Length with Collar 4.00"
• Tank Length 3.00"
• Tank Width 3.25"
• Tank Height 5.38"
• Collar Length 1.00"
• 0.55 Quarts Useable

KTI HYDRAULICS POLY RESERVOIR
• Overall Length with Collar 8.00"
• Tank Length 6.50"
• Tank Width 6.88"
• Tank Height 6.88"
• Collar Length 1.25"

THIEMAN STEEL RESERVOIR
• Overall Tank Length with Collar 10.00"
• Tank Length 9.00"
• Tank Diameter 6.00"
• Dual Hole
• Horizontal Mount
• 1 Gallon Useable

TOMMY LIFT GATE POLY RESERVOIR
• Tank Length 10.00"
• Tank Diameter 4.50"
• Single Hole
• Horizontal Mount
• 1.25 Quarts Useable

BUCHER POLY RESERVOIR
• Overall Length with Collar 15.00"
• Tank Length 13.00"
• Tank Width 6.75"
• Tank Height 6.75"
• Collar Length 2.00"
• 1.67 Gallons Useable

WALTCO STEEL RESERVOIR
• Tank Length 8.00"
• Tank Width 8.00"
• Tank Height 8.00"
• Three Hole
• 1.25 Quarts Useable

MAXON STEEL RESERVOIR
• Tank Length 10.50"
• Tank Width 8.00"
• Tank Height 6.50"
• Collar Length 2.00"
• 2.50 Gallons Useable

MAXON POLY RESERVOIR
• Overall Tank Length with Collar 8.50"
• Tank Length 7.00"
• Tank Width 6.50"
• Tank Height 6.00"
• Collar Length 1.50"
• 3 Quarts Useable

BUCHER POLY RESERVOIR
• Overall Length with Collar 20.00"
• Tank Length 18.00"
• Tank Width 6.75"
• Tank Height 6.75"
• Collar Length 2.00"
• 2.50 Gallons Useable

BUCHER STEEL RESERVOIR
• Overall Length with Collar 14.50"
• Tank Length 12.00"
• Tank Width 7.00"
• Tank Height 6.25"
• Collar Length 3.00"
• 2.00 Gallons Useable

MAXON POLY RESERVOIR
• Overall Tank Length with Collar 8.00"
• Tank Length 5.00"
• Tank Width 6.50"
• Tank Height 6.00"
• Collar Length 3.00"
• 3 Quarts Useable

BUCHER STEEL RESERVOIR
• Overall Length with Collar 24.00"
• Tank Length 21.00"
• Tank Width 7.25"
• Tank Height 6.25"
• Collar Length 2.50"
• 2.00 Gallons Useable

MAXON DUAL HOLE POLY RESERVOIR
• Overall Tank Length with Collar 7.00"
• Tank Length 5.50"
• Tank Width 10.50"
• Tank Height 9.50"
• Has Two Fill Holes

BUCHER POLY RESERVOIR
• Tank Length 8.00"
• Tank Diameter 4.50"
• Single Hole
• Horizontal Mount
• 0.95 Quarts Useable

BUCHER STEEL RESERVOIR
• Overall Length with Collar 11.50"
• Tank Length 10.00"
• Tank Width 7.25"
• Tank Height 6.25"
• Collar Length 1.50"
• 2.00 Gallons Useable

THIEMAN POLY RESERVOIR
• Tank Length 12.00"
• Tank Diameter 4.50"
• Single Hole
• Horizontal Mount
• 1.67 Quarts Useable

TOMMY GATE POLY RESERVOIR
• Tank Length 13.00"
• Tank Diameter 4.50"
• Single Hole
• 3.00 Quarts Useable

BUCHER POLY RESERVOIR
• Overall Length with Collar 11.08"
• Tank Length 10.08"
• Tank Width 3.25"
• Tank Height 5.38"
• Collar Length 1.00"
• 1.07 Quarts Useable

MAXON STEEL RESERVOIR
• Tank Length 10.50"
• Tank Width 8.00"
• Tank Height 6.50"
• Collar Length 2.00"
• Has Bottom Drain Hole
• 2.50 Gallons Useable

MAXON POLY RESERVOIR w/BRACKET
• Overall Tank Length with Collar 16.00"
• Tank Length 14.25"
• Tank Width 6.50"
• Tank Height 6.75"
• Collar Length 1.75"

MAXON STEEL RESERVOIR
• Tank Length 12.00"
• Tank Diameter 4.50"
• Dual Hole
• Horizontal Mount
• 3 Quarts Useable
